JM744X / JM644X hydraulic and pneumatic angle type quick opening mud valve

Product Type : Remote water meter
Introduction : JM744X hydraulic and pneumatic JM644x diaphragm type quick-opening mud valve adopts double-chamber diaphragm transmission mechanism instead of piston type mechanism, which has no movement wear and long service life. The inside of the diaphragm is made of folded composite material. Greatly improves the elongation of the diaphragm and prolongs the service life of the diaphragm during the opening and closing of the valve. Not easily broken. And can withstand higher pressure. Stay with electric two-position four-way valve or manual two-position four-way or to the valve centralized control, easy to operate, flexible valve opening and closing. This valve is mainly installed outside the bottom wall of the sedimentation tank to exclude the sediment and dirt at the bottom of the tank.

Product Details

Product Overview:

JM744X hydraulic and pneumatic JM644x diaphragm type quick-opening mud valve adopts double-chamber diaphragm transmission mechanism instead of piston type mechanism, which has no movement wear and long service life. The inside of the diaphragm is made of folded composite material. Greatly improves the elongation of the diaphragm and prolongs the service life of the diaphragm during the opening and closing of the valve. Not easily broken. And can withstand higher pressure. Stay with electric two-position four-way valve or manual two-position four-way or to the valve centralized control, easy to operate, flexible valve opening and closing. This valve is mainly installed outside the bottom wall of the sedimentation tank to exclude the sediment and dirt at the bottom of the tank.
